    TurboTenna 011XTS RF Amplifier Pen Booster

  • +27dBm 802.11b/g High Performance WiFi Amplifier
  • Compact and light weight with advanced HBT RF circuitry design
  • Easy installation for wireless router and access point
  • Detachable antenna
Please enter coupon code in the box. Leave it empty if you don't have one.
UNIT(S)
Unit Price
US$119.95
HongkongPost
INSURANCE

    Packaging Content
1)
TurboTenna 011XTS +27dBm (500mW) 802.11b/g RF Amplifier Pen Booster
1 unit
2)
+2dBi Rubber Duck Short Antenna
1 unit
3)
DC 6.0V x 500mA, AC 110 ~ 240V Power Adaptor
1 unit
4)
User guide
1 unit


    Features and Benefits

This +27dBm (500mW) TurboTenna 011XTS Pen Booster is designed to offer a straight neck which is ideal for cascading two sections of RF cables, or to fit in any 802.11b/g WiFi devices equipped with a RP-SMA-female RF connector. Its advanced RF circuitry offers an automatic gain adjustment and high Signal-to-Noise ratio that maintain the wireless connection at optimal speed with exceptional stability.

You may also connect the Pen Booster to other PCI and PCMCIA WiFI devices either directly or using the Universal Antenna Adapter Box and a matching pigtail.

The package comes with a 2dBi Rubber Duck. It can be replaced by more powerful directional antennae such as the Omni, TurboTenna 007GT waveguide booster and the Yagi to meet your coverage and range extension requirements.

TurboTenna 011XT Pen Booster is the Right Angled alternative also having a gain of +27dBm at 500mW.

    Specifications

Operating Range:
2400-2500 MHz

Signal Type:
DSSS/ FHSS

TX/RX Switch Time:
<1msec

Max Transmit Linear Output Power:
500mW/ 27dBm 802.11g

Transmit Gain:
up to 10dB

Transmit Input Power:
0 +/- 2dBm Min; +20dBm Max

Receive Gain:
12~16dB, 15dB typical

Max Receive Input Power:
-10dBm

TX Power Protection:
Auto Gain Adjustment

Noise Figure:
< 3.0dB typcial

RF Connector:
RP-SMA and RP-SMA-female

DC Power:
DC 6.0V x 500mA, AC 110 ~ 240V Power Adaptor

Operating Temperature:
-20 deg. C to 50 deg. C

Operating Humidity:
95% relative humidity

LED Indicator:
TX Green, RX Red

Size LxWxH (Without Antenna):
82mm x 22mm x 20mm

Weight:
80g (not including AC/DC adapter)

RF Cable:
Not included

TurboTenna® is a registered trademark of danets.
